Axle 39mm round LM Bearing Turned

Description

39mm solid round axle for LM (Holden) bearings are rated to a maximum of 750Kg with a recommended maximum tyre size of 14″

This axle is designed for the following bearings.
Inner bearing, 1 x Set 6 bearing – 67048 cone & 67010 cup (67048/10)
Outer bearing, 1 x Set 2 bearing – 11949 cone & 11910 cup (11949/10)

Maximum capacity: 750Kg
Maximum recommended tyre size: 14″

Axle length accuracy typically +/- 5mm

Most standard hubs to suit this axle have a tip of axle to face of hub conversion of 103mm (51.5mm/hub)
