Mister Hitches HD Series 152mm Drop 127mm Rise Towbar Tongue

Description

Mister Hitches towbar tongue HD series 152mm drop or 127mm rise.

• Fits 50mm square (2″ square) towbar receivers
• Reversible – raises or lowers ball to the right level for towing
• Black powder coated finish
• Robotic welded for consistent quality
• CNC machined for maximum accuracy
• Made tough for Australian conditions
• Extra heavy duty 25mm thick x 75mm wide tongue

Maximum trailer ATM : 3650Kg
Maximum ball weight: 365Kg
Shank hole diameter : 7/8″ (22mm)
Drop: 152mm(from top of 50mm shaft)
Rise: 127mm (from top of 50mm shaft)
Length: 242mm & 292mm (Measured from centre of receiver pin to centre of ball hole)

End of shank to first pin hole is 50mm (suits short shank receivers)

Note: Towing capacity of Tow Ball Mount may exceed towing capacity of towbar or vehicle, always refer to the towing capacity of towbar and vehicle.
