Mister Hitches 4000Kg Adjustable Ball Mount Towbar Tongue

$245.00

50mm Towball 3.5t - 7/8" x 52mm Shank Chrome

Mister Hitches Locking Hitch Pin

SKU: MHABM-5XHD
Share:

Description

The hitch is fully reversible which gives you 12 mounting adjustments. High tensile grade 12.9 mounting hardware make this one of the strongest & most versatile hitches on the market.

  • 3 pin holes to give lengths 261, 300 & 326mm
  • 12 adjustable positions
  • 6 stages of drop 80mm/110mm/130mm/140mm/160mm/190mm
  • 6 stages of rise 50mm/80mm/105mm/110mm/135mm/165mm
  • 10mm dual support gussets for added strength
  • New model with 3 pin holes
  • High tensile grade 12.9 bolts
  • 25mm x 75mm heavy duty ball platform
  • Seaguard matte black powder coat finish gives superior corrosion protection
  • Robotic welded for consistent quality
  • CNC Machined for maximum accuracy
  • Fits 50mm square (2″ square) towbar receivers

Maximum trailer ATM : 4000Kg
Maximum ball weight: 400Kg
Shank hole diameter : 7/8″ (22mm)
Drop: 80-186mm(from top of 50mm shaft)
Rise: 50-160mm (from top of 50mm shaft)
Length: 266, 305 & 331mm (Measured from centre of receiver pin to centre of ball hole)

End of shank to pin holes 50mm, 76mm & 115mm
End of shank to gusset 164mm

Suits stone stomper & most couplings eg. Cruisemaster do35

Note: Towing capacity of Tow Ball Mount may exceed towing capacity of towbar or vehicle, always refer to the towing capacity of towbar and vehicle.

Additional information

Weight 8.9 kg
Dimensions 30 × 19 × 9 cm
Brand

Capacity

Length

266mm, 305mm, 331mm

Inside Diameter
