AL-KO European Bearing 72mm OD x 39mm ID x 37mm

$105.00

SKU: 1224803
Share:

Description

Alko European wheel bearing kit 1224803.
72mm OD x 39mm ID x 37mm

Suitable for:
Alko axles 811002, 811135, 811158, 811268
Alko hubs 581063, 583928

Kit includes:

  • 1 x Wheel bearing 72mm OD x 39mm ID x 37mm
  • 2 x Circlip
  • 1 x 24mm one shot flange nut

Notes about Alko’s flange nut:

Used on Alko European suspensions. The Alko 24mm flange nut is a one shot nut and is designed to grip the thread to stop it backing off and once it has been removed it will need to be replaced.

This Alko 24mm nut needs to be torqued to 290Nm +/- 10Nm

Thread size: M24 (24mm x 1.5mm)
Flange size: 50mm
Socket size: 32mm
Torque setting: 290Nm +/- 10Nm

Please note some of the older hub nuts used a 36mm socket this has now been replaced with a 32mm.
One shot means the nut is designed to grip the thread to stop it backing off and once it has been undone it will need to be replaced.

1224803
991224803

Additional information

Weight .78 kg
Dimensions 34 × 16 × 4 cm
Brand

Inside Diameter

Outside Diameter
